www.ti.com

PACKAGE OUTLINE

12.1

11.9

12.1

11.9

1.321 MAX

0.393

0.293

196X

0.5

0.4

10.4 TYP

10.4 TYP

0.8 TYP

0.8 TYP

(0.8)

(0.8)

(0.448)

FCBGA - 1.321 mm max height

ACP0196A

BALL GRID ARRAY

4226793/B 07/2021

NOTES:

1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing

per ASME Y14.5M.

2. This drawing is subject to change without notice.

BALL A1

CORNER

0.1 C

0.2 C

SEATING PLANE

0.2 C

0.15

C A B

0.08

C

SYMM

SYMM

1

A

2

3

4

5

6

7

8

9

10

11

12 13

B

C

D

E

F

G

H

J

K

L

M

N

14

P

SCALE 1.200

A

B

C

TX08D

SBASAW7A – OCTOBER 2023 – REVISED JANUARY 2024

www.ti.com

4

Submit Document Feedback

Copyright © 2024 Texas Instruments Incorporated

Product Folder Links: TX08D
