Evaluation PCB

the circuit board used in the application should

use rF circuit design techniques. signal lines sho-

uld have 50 ohm impedance while the package

ground leads and exposed paddle should be con-

nected directly to the ground plane similar to that

shown. A sufficient number of via holes should be

used to connect the top and bottom ground planes.

the evaluation circuit board shown is available from

Hittite upon request.

Board is configured with wideband single-ended

input interface suitable for input signal frequencies

above 100 MHz. refer to wideband single-ended

input interface section in application information for

operating with signals below 100 MHz.

List of Materials for Evaluation PCB 129547 [1]

Item

Description

J1, J2

Pc Mount sMA connector

tP1 - tP9

Dc Pin

c1, c10, c16

100 pF capacitor, 0402 Pkg.

c2, c5, c11, c17

100 nF capacitor, 0402 Pkg.

c3, c4, c6

1000 pF capacitor, 0402 Pkg.

r2, r12 - r15

10K resistor, 0402 Pkg.

r3 - r5, r9, r10

0 ohm resistor, 0402 Pkg.

r6, r7

4.7K resistor, 0402 Pkg.

r11

100 ohm resistor, 0402 Pkg.

U1

HMc909LP4e

rMs Power Detector

PcB [2]

128683 evaluation PcB

[1] reference this number when ordering complete evaluation PcB

[2] circuit Board Material: rogers 4350

HMC909LP4E

v02.0511

RMS POWER DETECTOR

SINGLE-ENDED, DC - 5.8 GHz
