PowerPC 440SP Embedded Processor

AMCC Proprietary

Revision 1.23 - Sept 26, 2006

Data Sheet

Signal Description

The PPC440SP embedded controller is packaged in a 783-ball flip-chip plastic ball grid array (FC-PBGA). The

following table describes the package level pinout.

In the table “Signal Functional Description” on page 56, each I/O signal is listed along with a short description of its

function. Active-low signals (for example, RAS) are marked with an overline. Please see “Signals Listed

Alphabetically” on page 17 for the pin (ball) number to which each signal is assigned.

Table 5. Pin Summary

Group

No. of Pins

Signal pins, non-multiplexed

496

Signal pins, multiplexed

Total Signal Pins

528

AxVDD

APxVDD

AxGND

OVDD (3.3V I/Os)

PxVDD (3.3V-1.5V PCI)

SVDD G(2.5-1.8V SDRAM)

VDD (1.5V Logic)

GND

Total Power Pins

205

Reserved

Total Pins

783
