 2022 Microchip Technology Inc. and its subsidiaries

DS00002329E-page 73

KSZ9567R

5.1.1.8

Global Port Interrupt Status Register

This register provides the top level interrupt status for the individual ports. These interrupts are enabled in the Global

Port Interrupt Mask Register. Refer to the Port Interrupt Status Register for detailed port interrupt status.

Address:

0x0018 - 0x001B

Size:

32 bits

Bits

Description

Type

Default

31:7

RESERVED

Port 7 Interrupt Status

0 = No interrupt

1 = Interrupt request

Port 6 Interrupt Status

0 = No interrupt

1 = Interrupt request

Port 5 Interrupt Status

0 = No interrupt

1 = Interrupt request

Port 4 Interrupt Status

0 = No interrupt

1 = Interrupt request

Port 3 Interrupt Status

0 = No interrupt

1 = Interrupt request

Port 2 Interrupt Status

0 = No interrupt

1 = Interrupt request

Port 1 Interrupt Status

0 = No interrupt

1 = Interrupt request
