6 / 16 page ![]() AD8372 Rev. 0 | Page 6 of 16 ABSOLUTE MAXIMUM RATINGS Table 4. Parameter Rating Supply Voltage, VS 5.5 V ENB1, ENB2, SDI1, SDI2, SDO1, SDO2, CLK1, CLK2, LCH1, LCH2 VS + 500 mV Differential Input Voltage, VIPC1 − VINC1, VIPC2 − VINC2 V p-p Internal Power Dissipation 1.4 W θJA (Exposed Paddle Soldered Down) 34.6°C/W1, 2 θJC (At Exposed Paddle) 3.6°C/W2 Maximum Junction Temperature 150°C Operating Temperature Range −40°C to +85°C Storage Temperature Range −65°C to +150°C 1 Still air. 2 All values are modeled using a standard 4-layer JEDEC test board with the pad soldered to the board and thermal vias in the board. Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. This is a stress rating only; functional operation of the device at these or any other conditions above those indicated in the operational section of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability. ESD CAUTION |
|
|
