SRP4012CC Series - Shielded Power Inductors

Product Dimensions

1R0

3.95 ± 0.2

(.156 ± .008)

TOP VIEW

SIDE VIEW

BOTTOM VIEW

4.45 ± 0.25

(.175 ± .010)

1.0 ± 0.2

(.039 ± .008)

4.06 ± 0.25

(.160 ± .010)

2.0 ± 0.2

(.079 ± .008)

0.76 ± 0.3

(.030 ± .012)

DIMENSIONS:

MM

(INCHES)

Recommended Layout

5.2

(.205)

2.2

(.087)

2.3

(.091)

DIMENSIONS:

MM

(INCHES)

Electrical Schematic

How to Order

SRP4012CC - R10Y

Model

Value Code (see table)

Specifications are subject to change without notice.

Users should verify actual device performance in their specific applications.

The products described herein and this document are subject to specific legal disclaimers as set forth on the last page of this document, and at www.bourns.com/docs/legal/disclaimer.pdf.

L vs. IDC and Temperature vs. IDC Curves

0.15

0.12

0.09

0.06

0.03

0

0.20

0.16

0.12

0.08

0.04

0

0

5

10

15

20

25

DC Current (A)

0

5

10

15

20

25

DC Current (A)

100

80

60

40

20

0

100

80

60

40

20

0

SRP4012CC-R10Y

0.40

0.32

0.24

0.16

0.80

0

0

2.8

5.6

8.4

11.2

14.0

DC Current (A)

100

80

60

40

20

0

SRP4012CC-R33M

0.50

0.40

0.30

0.20

0.10

0

024

10

6

8

0

1.8

3.6

5.4

9.0

7.2

DC Current (A)

100

80

60

40

20

0

SRP4012CC-R36M

0.65

0.52

0.39

0.26

0.13

0

DC Current (A)

100

80

60

40

20

0

SRP4012CC-R47M

SRP4012CC-R15Y

0.30

0.24

0.18

0.12

0.06

0

0

5

10

15

20

25

DC Current (A)

100

80

60

40

20

0

SRP4012CC-R22M
