IP1718 LF

Preliminary Data Sheet

6/33

January 27, 2005

IP1718 LF-DS-R05

Pin description

Type

Description

Positive power or ground

I; O

I: Input pin; O:Output pin

Input latched upon reset

Type

Description

PD,

PD:Pulled down with internal resistor

PU:Pulled up with internal resistor

I/O

Bi-direction Input/Output

Pin No.

Label

Type

Description

SS-SMII

117, 119

121, 123,

128, 7,

9, 11,

15, 17,

19, 21,

28, 31,

33, 35,

P1TXD, P2TXD,

P3TXD, P4TXD,

P5TXD, P6TXD,

P7TXD, P8TXD,

P9TXD, P10TXD,

P11TXD, P12TXD,

P13TXD, P14TXD,

P15TXD, P16TXD,

SS-SMII transmit data output for port 1 to port 16.

126,

26,

TXSYNC1,

TXSYNC2,

SS-SMII synchronization output for transmit data

127,

27,

TXCLK1,

TXCLK2,

SS-SMII transmit clock output

118, 120,

122, 124,

6, 8,

10, 12,

16, 18,

20, 22,

30, 32,

34, 36,

P1RXD, P2RXD,

P3RXD, P4RXD,

P5RXD, P6RXD,

P7RXD, P8RXD,

P9RXD, P10RXD,

P11RXD, P12RXD,

P13RXD, P14RXD,

P15RXD, P16RXD,

SS-SMII receive data input

42, 44,

46, 48,

56, 60,

62, 64

49, 55

GND

Should be tied to GND.

125,

25,

RXSYNC1,

RXSYNC2,

SS-SMII receive synchronization input

29,

RXCLK1,

RXCLK2,

SS-SMII receive clock input
