IP1726 LF

Preliminary Data Sheet

3/33

Jun 15, 2005

IP1726 LF-DS-R06

Revision History

Revision #

Change Description

IP1726 LF-DS-R01 Initial release.

IP1726 LF-DS-R02 Revise the pin diagram. Revise the pin description. Revise the register description.

IP1726 LF-DS-R03 Revise the feature. Revise pin 21, pin 43, pin 47, pin 45, pin 63, pin 79, pin 74 in pin

description. Add MDC, MDIO to pin description. Rename MII port 1 to 1st MII (port

25) and MII port 2 to 2nd MII (port 26). Revise data rate control section, the

baroadcast storm control section and handling the higher layer proocol section.

Functions for pin 117 & pin 119 are re-defined. The register 2 description is revised.

Revise the timing chart of the SCPUIO and SCPUC.

IP1726 LF-DS-R04 Revise the pin diagram. Revise the pin description for pin 89, pin 90, pin 105, and pin

106.

IP1726 LF-DS-R05 Add the order information for lead free package.

IP1726 LF-DS-R06 Modify the pin description of pin 107, pin 108, pin 109, pin 110, pin 111 and pin 112.

For CoS hardware setting.
