JN2AS04MK2-R Arkusz danych(PDF) 2 Page - Japan Aviation Electronics Industry, Ltd.

Numer części JN2AS04MK2-R
Szczegółowy opis  Small circular connector, With construction having earth function, 4 pos., Panel mount receptacle
PDF  3 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Producent  JAE [Japan Aviation Electronics Industry, Ltd.]
Strona internetowa  http://www.jae.com
Logo JAE - Japan Aviation Electronics Industry, Ltd.

JN2AS04MK2-R Arkusz danych(HTML) 2 Page - Japan Aviation Electronics Industry, Ltd.

  JN2AS04MK2-R Datasheet HTML 1Page - Japan Aviation Electronics Industry, Ltd. JN2AS04MK2-R Datasheet HTML 2Page - Japan Aviation Electronics Industry, Ltd. JN2AS04MK2-R Datasheet HTML 3Page - Japan Aviation Electronics Industry, Ltd.
Zoom Inzoom in Zoom Outzoom out
 2 / 3 page
background image
Contact Size X No. of Contacts
#20*4
Applicable Wire (Cross-
sectional Area of Conductor)
　　
Applicable Wire Insulation
Diameter
　　
Polarizing Key Position
Normal position
Material of Contact
copper alloy
Finish of Contact in Connecting
Area
Silver plating
Outer Shell Color
Black
Total Current Rating (A)
　　
Contact Resistance (milliohm)
　　
Dielectric Withstanding
Voltage (1 minute)
2,000VAC
Insulation Resistance
1,000MΩMIN
Mating Cycles
500 times
Operating Temperature Range
-20 Deg. C to +100 Deg. C
Applicable Contacts
　　
Applicable Housing
　　
Applicable Accessory
　　
Applicable Product Part
Numbers
　　
Applicable Wire Diameter
　　
RoHS compliant
10 substances (2011/65/EU, (EU)2015/863)
REACH compliant
Combination
JN1DS04FK1
JN1DS04FK2
JN1DS04FK3
JN1DS04FKK
JN1FS04FK1
JN1FS04FK2
JN1FS04FKK
