HCC4512B

HCF4512B

8–CHANNEL DATA SELECTOR

DESCRIPTION

.

3-STATE OUTPUT

.

STANDARDIZED

SYMMETRICAL

OUTPUT

CHARACTERISTICS

.

QUIESCENT CURRENT SPECIFIED TO 20V

FOR HCC DEVICE

.

5V, 10V, AND 15V PARAMETRIC RATINGS

.

INPUT CURRENT OF 100nA AT 18V AND 25

°C

FOR HCC DEVICE

.

100% TESTED FOR QUIESCENT CURRENT

.

MEETS ALL REQUIREMENTS OF JEDEC TEN-

TATIVE STANDARD No. 13A, ”STANDARD

SPECIFICATIONS FOR DESCRIPTION OF ”B”

SERIES CMOS DEVICES”

June 1989

The HCC4512B (extended temperature range) and

HCF4512B (intermediate temperature range) are

monolithic integrated circuit, available in 16-lead

dual in-line plastic or ceramic package and plastic

micro package.

The HCC/HCF4512B is an 8-channel data selector

featuring a three-state output that can interface di-

rectly with, and drive, data lines of bus-oriented sys-

tems.

EY

(Plastic Package)

F

(Ceramic Package)

ORDER CODES :

HCC4512BF

HCF4512BM1

HCF4512BEY

HCF4512BC1

PIN CONNECTIONS

C1

(Chip Carrier)

M1

(Micro Package)

1/12
