MIC24054

DS20007043B-page 30



2025-2026 Microchip Technology Inc. and its subsidiaries

9.0

PACKAGING INFORMATION

9.1

Package Marking Information

Note:

If the full seven-character YYWWNNN code cannot fit on the package, the following truncated codes are

used based on the available marking space:

6 Characters = YWWNNN; 5 Characters = WWNNN; 4 Characters = WNNN; 3 Characters = NNN;

2 Characters = NN; 1 Character = N

Example

28-Lead VQFN*

XXX

XXXXXXXX

WNNN

MIC

24054YJL

6LB1

Legend: XX...X Product code or customer-specific information

Year code (last digit of calendar year)

Year code (last 2 digits of calendar year)

Week code (week of January 1 is week ‘01’)

NNN

Alphanumeric traceability code

Pb-free JEDEC® designator for Matte Tin (Sn)

This package is Pb-free. The Pb-free JEDEC designator (

)

can be found on the outer packaging for this package.

●, ▲, ▼ Pin one index is identified by a dot, delta up, or delta down (triangle

mark).

Note: In the event the full Microchip part number cannot be marked on one line, it will

be carried over to the next line, thus limiting the number of available

characters for customer-specific information. Package may or may not include

the corporate logo.

Underbar (_) and/or Overbar (‾) symbol may not be to scale.
