14 / 58 page  SSM3582A Data Sheet Rev. A | Page 14 of 58 TYPICAL PERFORMANCE CHARACTERISTICS 20 10 –180 FREQUENCY (Hz) 0 –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 –120 –130 –140 –150 –160 –170 60dBFS INPUT ANALOG GAIN = 6.3V peak RL = 4Ω (LOW EMI) Figure 7. Amplitude vs. Frequency, 60 dBFS Input, Analog Gain = 6.3 V peak 20 10 –180 FREQUENCY (Hz) 0 –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 –120 –130 –140 –150 –160 –170 60dBFS INPUT ANALOG GAIN = 8.9V peak RL = 4Ω (LOW EMI) Figure 8. Amplitude vs. Frequency, 60 dBFS Input, Analog Gain = 8.9 V peak 20 10 –180 FREQUENCY (Hz) 0 –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 –120 –130 –140 –150 –160 –170 60dBFS INPUT ANALOG GAIN = 12.6V peak RL = 4Ω (LOW EMI) Figure 9. Amplitude vs. Frequency, 60 dBFS Input, Analog Gain = 12.6 V peak 20 10 –180 FREQUENCY (Hz) 0 –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 –120 –130 –140 –150 –160 –170 60dBFS INPUT ANALOG GAIN = 16V peak RL = 4Ω (LOW EMI) Figure 10. Amplitude vs. Frequency, 60 dBFS Input, Analog Gain = 16 V peak 20 10 –180 FREQUENCY (Hz) 0 –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 –120 –130 –140 –150 –160 –170 NO SIGNAL ANALOG GAIN = 6.3V peak RL = 4Ω (LOW EMI) Figure 11. Amplitude vs. Frequency, No Signal, Analog Gain = 6.3 V peak 20 10 –180 FREQUENCY (Hz) 0 –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 –120 –130 –140 –150 –160 –170 NO SIGNAL ANALOG GAIN = 8.9V peak RL = 4Ω (LOW EMI) Figure 12. Amplitude vs. Frequency, No Signal, Analog Gain = 8.9 V peak |
|
