1 OSLON® Square Large Lens High CRI

ILH-OG01-##90-SC221-WIR200.

Product Overview

At the heart of each OSLON® Square PowerStar high CRI is one

of the worlds most compact 2W high power LEDs with extremely

low thermal resistance, remarkable high efficiency, highly reliable

and superior corrosion robustness. The latest generation of the

OSLON® Square still emits with a viewing angle of 120˚ but due

to an increase in size of the silicone lens this improves the radiation

pattern and enhances the performance. PowerStars are compact,

powerful LED light sources built on aluminium substrates for optimal

thermal management. Available with 200mm wires as standard.

Applications

z

General Lighting

z

Spot Lighting

z

Task Lighting

z

Decorative Lighting

z

Horticultural Lighting

z

Retail and Entertainment Lighting

Technical Features

z

OSLON® PowerStars contain a single OSRAM Opto Semiconductors OSLON® SSL Square LED

z

Up to 50,000 hours lifetime to 70% of original brightness

z

Mounting holes using M3 screws allow easy installation

z

Size (LxWxH): 20x20x3.62mm

z

PowerStars can be linked together to produce longer chains

z

Current range 200mA to 1800mA*

z

High CRI 90 minimum

*This datasheet should be read in conjunction with the relevant OSRAM Opto Semiconductors data on the LED used

Suitable Heatsinks available - please see Heatsink section

Suitable Lenses available - Please see Lens section

Suitable Drivers available - Please see drivers section
