Configuration data
STFPC320
48/78
13
Configuration data
To read the configuration data from STFPC320, 0x71 command (Section 7.2: Data setting
command on page 36) is sent from the Host to STFPC320. After this, the STFPC320 will
output a maximum of 14 bytes with the configuration data. The Host can choose to read only
a few bytes by pulsing the SCL line according to the number of bytes to be read.
Up to a maximum of 14-bytes are sent from MSB to LSB as configuration data. The 14-bytes
represent the following configuration information.
Figure 21.
Configuration data bytes
RTC Display format
VFD Dimming and (ON/OFF) status
MSB
LSB
Clock init display location
No. of VFD display digits
MSB
LSB
RC Protocol
Guard Timer Value
MSB
LSB
b7
b4
b3
b0
b7
b4
b3
b0
b7
b4 b3
b0
Front Panel Hot Keys (1st Byte)
MSB
LSB
b7
b0
Front Panel Hot Keys (2nd Byte)
MSB
LSB
b7
b0
Front Panel Hot Keys (3rd Byte)
MSB
LSB
b7
b0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
RC Device Address 1
MSB
LSB
b7
b0
Byte 7
RTC Display format
VFD Dimming and (ON/OFF) status
MSB
LSB
Clock init display location
No. of VFD display digits
MSB
LSB
RC Protocol
Guard Timer Value
MSB
LSB
b7
b4
b3
b0
b7
b4
b3
b0
b7
b4 b3
b0
Front Panel Hot Keys (1st Byte)
MSB
LSB
b7
b0
Front Panel Hot Keys (2nd Byte)
MSB
LSB
b7
b0
Front Panel Hot Keys (3rd Byte)
MSB
LSB
b7
b0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
RC Device Address 1
MSB
LSB
b7
b0
Byte 7
