STLED316S

Package mechanical data

31/33

Package mechanical data

In order to meet environmental requirements, ST offers these devices in ECOPACK®

packages. These packages have a Lead-free second level interconnect. The category of

second level interconnect is marked on the package and on the inner box label, in

compliance with JEDEC Standard JESD97. The maximum ratings related to soldering

conditions are also marked on the inner box label. ECOPACK is an ST trademark.

ECOPACK specifications are available at: www.st.com.

Figure 10.

SO-24 package outline

Table 20.

SO-24 package mechanical data

Symbol

millimeters

inches

Min

Typ

Max

Min

Typ

Max

2.35

2.65

0.093

0.104

0.1

0.30

0.004

0.012

0.33

0.51

0.013

0.020

0.23

0.32

0.009

0.013

15.20

15.60

0.598

0.614

7.4

7.6

0.291

0.299

1.27

0.050

10.00

10.65

0.394

0.419

0.25

0.75

0.010

0.030

0.4

1.27

0.016

0.050

ddd

0.100

0.004

0070769C
