Package information
TS2012
28/30
Figure 48.
QFN20 package footprint
Note:
The QFN20 package has an exposed pad E2 x D2. For enhanced thermal performance, the
exposed pad must be soldered to a copper area on the PCB, acting as a heatsink. This
copper area can be electrically connected to pin 4, 12, 18 (PGND, AGND) or left floating.
Table 10.
QFN20 package mechanical data
Ref
Dimensions in mm
Min
Typ
Max
A0.8
0.9
1
A1
0.02
0.05
A2
0.65
1
A3
0.25
b
0.18
0.23
0.3
D
3.85
4
4.15
D2
2.6
E
3.85
4
4.15
E2
2.6
e
0.45
0.5
0.55
L0.3
0.4
0.5
ddd
0.08
A4.55
B4.55
C0.50
D0.35
E0.65
F2.45
G0.40
FOOTPRINT DATA (mm)
