Section 8 User Break Controller (UBC)

Rev. 2.00 Sep. 24, 2008 Page 181 of 1468

REJ09B0412-0200

CKS

The value read as 1

is retained

Flag bit

Flag bit is set to 1

Flag bit is cleared to 0

Figure 8.3 Flag Bit Clearing Sequence (Condition Match Flag)

4. After setting break conditions for the UBC, an unexpected UBC break interrupt may occur

after the execution of an illegal instruction. This depends on the value of the program counter

and the internal bus cycle.
