Section 19 Serial Communication Interface (SCI, IrDA, CRC)
Rev. 2.00 Sep. 24, 2008 Page 943 of 1468
REJ09B0412-0200
Initialization
No
Yes
Clear TE bit in SCR to 0
Start transmission
Start
No
No
No
Yes
Yes
Yes
Yes
No
End
Write data to TDR and clear
TDRE flag in SSR to 0
Error processing
Error processing
TEND = 1?
All data transmitted?
TEND = 1?
ERS = 0?
ERS = 0?
Figure 19.31 Sample Transmission Flowchart
