Rev. 1.08.09_149

LPS50-M Series

 of 3

Embedded Power for

Business-Critical Continuity

Operatingtemperature:

0°to50°Cambientderateeachoutputas2.5%perdegreefrom50°to70°C.

-20°Cstartup

Storagetemperature:

-40°Cto+85°C

Electromagneticsusceptibility: DesignedtomeetEN61000-4;-2,-3,-4,-5,-6,-8,-11Level3

Humidity:

Operating;non-condensing10%to95%RH

Vibration:

IEC68-2-6tothelevelsofIEC721-3-2

MTBFdemonstrated:

>550,000hoursatfullloadand25°Cambientconditions

EnvironmentalSpecifications

MechanicalDrawing

3.75"

[95.3]

4.00"

[101.6]

0.16"

[4.0]

R22

SK1

TH1

C1

F2

L1

F1

C5

L3

DB1

C32

C24

C30

C17

C9

C18

Q6

T1

D4

R1

LED1

D2

T2

C22

SK2

C27

R3A

R3

Q5

L2

VR1

T3.15A 2.5A

250VAC

2005

+

GRN/

YEL

~

~

B

A

HTSK_SEC

C4

1

TP1

J

I

J3

F

H

J2

E

G

J1

D

TP2

J4

Mounting Hole

Ø0.16"[4.0] 4 Places

Max. Screw Head

Diameter .22” (5.6)

GND

3

1

M1

6

1

M2

0.197” (5.0) Minimum Standoff Height

VR1

Output Voltage

Adjust pot
