1207

BU-SB07326

Page 6 of 7

Data Sheet 4311

SECTION A-A

2.00 ±0.1

0.1

4.00

Ø1.50 +0.1/-0.0

16.00

0.3

7.50±0.1

1.75±0.10

Ø1.50 Min.

12.00

DRQ74 Series

Supplied in tape and reel packaging,

1100 parts per reel, 13" diameter reel.

SECTION A-A

1.5 dia

+0.1/-0.0

1.5 dia

min

4.0

2.0

16.00

1.7

11.5

24.0

+/-0.3

DRQ125 Series

Supplied in tape and reel packaging,

600 parts per reel, 13" diameter reel.

SECTION A-A

R0.3 max.

R0.5 TYP.

1.5 dia

+0.1/-0.0

1.5 dia

min

4.0

2.0

20.00

1.7

11.5

24.0

+/-0.3

DRQ127 Series

Supplied in tape and reel packaging,

350 parts per reel, 13" diameter reel.

Packaging Information

DRQ73 Series

Supplied in tape and reel packaging,

1350 parts per reel, 13" diameter reel.

Dimensions are in millimeters.

Direction of Feed

Ao=7.90mm

Bo=7.90mm

Ko=3.80mm

Ao=7.90mm

Bo=7.90mm

Ko=4.70mm

Ao=13.00mm

Bo=13.00mm

Ko=6.30mm

Ao=13.00mm

Bo=13.00mm

Ko=8.30mm

ACTUAL SIZE

DRQ73

ACTUAL SIZE

DRQ74

ACTUAL SIZE

DRQ125

ACTUAL SIZE

DRQ127
