www.glenair.com
E-Mail: sales@glenair.com
J-9
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
© 2006 Glenair, Inc.
Printed in U.S.A.
CAGE Code 06324
TABLE II: SHELL SIZE
Shell
Size
A Thread
Class 2B
E
+.060 (1.5)
F
+.090 (2.3)
G
+.060 (1.5)
H
+.090 (2.3)
Tubing Size
Max
11
3/4-20 UNEF
.750 (19.1) 1.020 (25.9)
.810 (20.6) 1.220 (31.0)
16
13
7/8-20 UNEF
.760 (19.3) 1.050 (26.7)
.880 (22.4) 1.290 (32.8)
20
15
1-20 UNEF
.780 (19.8) 1.070 (27.2)
.940 (23.9) 1.350 (34.3)
24
23
1 7/16-18 UNEF
.890 (22.6) 1.180 (30.0) 1.190 (30.2) 1.730 (43.9)
40
TABLE III: FINISH
SYM
MATERIAL
FINISH
XM
Composite
Electroless Nickel
XW
Composite
Cadmium O.D. Over
Electroless Nickel
XO
Composite
No Plating–Base
189-039
Composite Connector Backshell Adapter for
MIL-PRF-28876 Fiber Optic Connectors
Straight, 45o and 90o
TABLE I: TUBING SIZE
Dash
No.
Conduit
I.D.
J Dia
Max
06
.188 (4.8)
.790 (20.1)
09
.281 (7.1)
.985 (25.0)
10
.312 (7.9)
.985 (25.0)
12
.375 (9.5) 1.035 (26.3)
14
.437 (11.1) 1.100 (27.9)
16
.500 (12.7) 1.160 (29.5)
20
.625 (15.9) 1.285 (32.6)
24
.750 (19.1) 1.480 (37.6)
28
.875 (22.2) 1.670 (42.4)
32
1.000 (25.4) 1.720 (43.7)
40
1.250 (31.8) 2.100 (53.3)
48
1.500 (38.1) 2.420 (61.5)
