SE2598L-R Arkusz danych(PDF) 1 Page - SiGe Semiconductor, Inc. |
|
|
|||||||||||||||||||||||||||||
SE2598L-R Arkusz danych(HTML) 1 Page - SiGe Semiconductor, Inc. |
|
|
1 / 2 page  SE2598L 2.4 GHz Power Amplifier with Power Detector Preliminary Information Applications DSSS 2.4 GHz WLAN (IEEE802.11b) OFDM 2.4 GHz WLAN (IEEE802.11g or IEEE802.11n) Access Points, PCMCIA, PC cards Features Single 3.3 V Supply Operation o 19 dBm, EVM = 3 %, 802.11g, OFDM 54 Mbps o 23 dBm, ACPR < -32 dBc, 802.11b 28 dB Gain Integrated temperature compensated power detector Integrated power amplifier enable pin (VEN) Lead Free, Halogen Free and RoHS compliant Small package: 16 pin 3 mm x 3 mm x 0.9 mm QFN Ordering Information Part Number Package Remark SE2598L 16 Pin QFN Samples SE2598L-R 16 Pin QFN Tape and Reel SE2598L-AK1 Application Kit Standard Product Description The SE2598L is a 2.4 GHz power amplifier designed for use in the 2.4 GHz ISM band for wireless LAN applications. The device incorporates a power detector for closed loop monitoring of the output power. The SE2598L includes a digital enable control for device on/off control. The SE2598L temperature compensated power detector is highly immune to mismatch at its output with less than 1.5 dB of variation with a 2:1 mismatch. Functional Block Diagram Figure 1: Functional Block Diagram DST-00215 Rev 1.3 Sep-29-2009 Confidential 1 of 2 |
