ADP2116

Rev. 0 | Page 5 of 36

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

VDD to GND

−0.3 V to +6 V

VIN1, VIN2, VIN3, VIN4, VIN5, VIN6 to

PGND1, PGND2, PGND3, PGND4

−0.3 V to +6 V

EN1, EN2, SCFG, FREQ, SYNC/CLKOUT,

PGOOD1, PGOOD2, V1SET, V2SET,

COMP1, COMP2, SS1, SS2 to GND

−0.3 V to (VDD + 0.3 V)

FB1, FB2 to GND

−0.3 V to +3.6 V

SW1, SW2, SW3, SW4 to PGND1, PGND2,

PGND3, PGND4

−0.3 V to (VDD + 0.3 V)

PGND1, PGND2, PGND3, PGND4 to GND

±0.3 V

VIN1, VIN2, VIN3, VIN4, VIN5, VIN6 to VDD

±0.3 V

θJA, JEDEC 1S2P PCB, Natural Convection

34°C/W

Operating Junction Temperature Range

−40°C to +125°C

Storage Temperature Range

−65°C to +150°C

Maximum Soldering Lead

Temperature (10 sec)

260°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Absolute maximum ratings apply individually only, not in

combination.

ESD CAUTION
