Programmable Flags
2-4
ADSP-BF506F EZ-KIT Lite Evaluation System Manual
PF4
RFS0/PWM0_CH/PPI_D10/
TACLK0
Default: PB1
Land grid array, expansion interface II
PF5
RFS0/PWM0_CH/PPI_D10/
TACLK0
Default: not used
Land grid array, expansion interface II
PF6
UA1_TX/PWM0_TRIP/
PPI_D12
Default: not used
Land grid array, expansion interface II
PF7
UA1_RX/PWM0_SYNC/
PPI_D13/TACI3
Default: not used
Land grid array, expansion interface II
PF8
UA1_RTS/DT0SEC/PPI_D7
Default: not used
Land grid array, expansion interface II
PF9
UA1_CTS/DR0SEC/PPI_D6/
CZM0
Default: not used
Land grid array, expansion interface II
PF10
SPI0_SCK/TMR2/PPI_D5
Default: SPI0_SCK
Land grid array, expansion interface II
PF11
SPI0_MISO/PWM0_TRIP/
PPI_D4/TACLK2
Default: SPI0_MISO
Land grid array, expansion interface II
PF12
SPI0_MOSI/PWM0_SYNC/
PPI_D3
Default: SPI0_MOSI
Land grid array, expansion interface II
PF13
SPI0_SEL1/TMR3/PPI_D2/
SPI0_SS
Default: SPI0_SEL1
Land grid array, expansion interface II
PF14
SPI0_SEL2/PWM0_AH/
PPI_D1
Default: not used
Land grid array, expansion interface II
PF15
SPI0_SEL3/PWM0_AL/
PPI_D0
Default: not used
Land grid array, expansion interface II
Table 2-1. Port F Programmable Flag Connections (Cont’d)
Processor Pin
Other Processor Function
EZ-KIT Lite Function
