Part List for Application Circuit: Figure 1

Item

Symbol

Description

Detail

1

IC-1

SA9103C

DIP-20/SOIC-20

2

IC-2

Opto Coupler 4N35

DIP-6

3

IC-3

Opto Coupler 4N35

DIP-6

4

D1

Diode, Silicon, 1N4148

5

D2

Diode, Silicon, 1N4148

6

D3

Diode, Silicon, 1N4148

7

ZD1

Diode, Zener, 2.4V, 200mW

8

ZD2

Diode, Zener, 2.4V, 200mW

9

XTAL

Crystal, 3.5795MHz

Colour burst TV

10

R1

Resistor, 1% metal

Note 1

11

R2

Resistor, 1% metal

Note 1

12

R3

Resistor, 390k, (230VAC), 1% metal

13

R4

Resistor, 1M, 1/4W, 1% metal

14

R5

Resitor, 470

Ω, 2W, 5%, carbon

15

R6

Resistor, 24k, 1/4W, 1%, metal

16

R7

Resistor, 24k, 1/4W, 1%, metal

17

R8

Resistor, 680

Ω, 1/4W, 5%

18

R9

Resistor, 680

Ω, 1/4W, 5%

19

R10

Resistor, 680

Ω, 1/4W, 5%

20

R11

Resistor, 100k, 1/4W, 5%

21

R12

Resistor, 120

Ω, 1/4W, 5%

22

R13

Resistor, 120k, 1/4W, 5%

23

R14

Resistor, 3.9k, 1/4W, 5%

24

R15

Resistor, 120

Ω, 1/4W, 5%

25

C1

Capacitor, 560pF

26

C2

Capacitor, 560pF

27

C3

Capacitor, 3.3nF

28

C4

Capacitor, 3.3nF

29

C9

Capacitor, 100nF

30

C10

Capacitor, 100nF

31

C11

Capacitor, 0.47µF, 250VAC, polyester

32

C12

Capacitor, 100nF

33

C13

Capacitor, 100µF

34

C14

Capacitor, 100µF

35

C15

Capacitor, 820nF

36

RSH

Shunt Resistor

Note 2

Note 1: Resistor (R1 and R2) values are dependant upon the selected value of RSH.

Note 2: See TYPICAL APPLICATIONS when selecting the value for RSH.
