POWER MANAGEMENT

SC1453

Applications Information (Cont.)

Inserting these values into equation (2) gives us:

()

108

150

744

465

)

MAX

(

•

−

Using this figure, we can calculate the maximum thermal

impedance allowable to maintain T

J ≤ 125°C:

() ()

370

108

125

)

MAX

(

)

MAX

(

)

MAX

(

)

MAX

(

−

With the standard SOT-23-5/TSOT-23-5 Land Pattern

shown at the end of this datasheet, and minimum trace

widths, the thermal impedance junction to ambient for

SC1453ISK is 256°C/W. Thus no additional heatsinking

is required for this example.

The junction temperature can be reduced further (or

higher power dissipation can be allowed) by the use of

larger trace widths and connecting PCB copper to the

GND pin (pin 2), which connects directly to the device

substrate. Adding approximately one square inch of PCB

copper to pin 2 will reduce

JA to approximately

130°C/W and T

J(MAX)

for the example above to

approximately 100°C for the SOT-23-5 package. The use

of multi layer boards with internal ground/power planes

will lower the junction temperature and improve overall

output voltage accuracy.

Layout Considerations

While layout for linear devices is generally not as critical

as for a switching application, careful attention to detail

will ensure reliable operation.

1) Attaching the part to a larger copper footprint will

enable better heat transfer from the device, especially

on PCBs where there are internal ground and power

planes.

2) Place the input, output and bypass capacitors close

to the device for optimal transient response and device

behaviour.

3) Connect all ground connections directly to the ground

plane. If there is no ground plane, connect to a common

local ground point before connecting to board ground.
