 9 / 16 page
background image
Tel: 886-2-66296288
Fax: 886-2-29174598
URL: http://www.princeton.com.tw
PT2260 V1.4
- 9 -
April, 2006
Remote Control Encoder
PT2260
ABSOLUTE MAXIMUM RATINGS
Parameter
Symbol
Conditions
Ratings
Unit
Supply voltage
Vcc
-0.3 ~ 10.0
V
Input voltage
VI
-0.3 ~ Vcc+0.3
V
Output voltage
VO
-0.3 ~ Vcc+0.3
V
Maximum power dissipation
Pa
Vcc=10V
500
mW
Operating temperature
Topr
-40 ~ +85
℃
Storage temperature
Tstg
-65 ~ +150
℃
DC ELECTRICAL CHARACTERISTICS
Parameter
Symbol
Test Conditions
Min.
Typ.
Max.
Unit
Supply voltage
Vcc
1.8
10
V
Stand-by current
Isb
Vcc=5V, OSC stops
All input pins open
0.2
0.5
0.8
µA
DOUT output driving current
IOH
Vcc=3V, VOH=1.5V
Vcc=10V, VOH=5 V
2.5
20
mA
DOUT output sinking current
IOL
Vcc=3V, VOL=1.5V
Vcc=10V, VOL=5V
4.6
24
mA
Operation current
Iop
Vcc=1.8V
Vcc=6.0V
Vcc=10V
0.01
0.50
1.60
mA
