AMF2805S/EM Arkusz danych(PDF) 1 Page - International Rectifier |
|
|
|||||||||||||||||||||||||||||
AMF2805S/EM Arkusz danych(HTML) 1 Page - International Rectifier |
|
|
1 / 7 page  09/15/08 www.irf.com 1 Description n 12W Output Power n Available in ±5V, ±12V and ±15V Outputs n 16 - 40VDC Input Range (28VDC Nominal) n Low Input/Output Noise n Total Ionizing Dose > 25KRads (Si) n SEE Hardened to LET up to 60MeV.cm 2 /mg n -55°C to +125°C Operating Range n Indefinite Short Circuit Protection n Flexible Mounting n High Power Density n Fully Isolated - Input to Output and to Case n Complimentary EMI Filter Available n Externally Synchronizable n Electrical Performance Similar to AHF28XXD Series n Standard Microcircuit Drawings Available Features AMF 28V Input, Dual Output The AMF28XXD has been designed for high density using chip and wire hybrid technology that complies with the class H requirements of MIL-PRF-38534. Manufactured in a facility fully qualified to MIL-PRF-38534, these converters are fabricated utilizing DSCC qualified processes. For available screening options, refer to device screening tableinthedata sheet. Applicable generic lot qualification test data including radiation performance can be made available on request. Consult IR Santa Clara for special requirements. AMF28XXD SERIES The AMF28XXD series of DC/DC converter modules has been specifically designed for operation in moderate radiation environments supplementing the higher radiation performance available in the International Rectifier ART2815T converter series. Environments presented to space vehicles operating in low earth orbits, launch boosters, orbiting space stations and similar applications requiring a low power, high performance converter with moderate radiation hardness performance will be optimally served by the AMF28XXD series. The physical configuration of the AMF28XXD series permits mounting directly to a heat conduction surface without the necessity of signal leads penetrating the heat sink surface. This package configuration permits greater independence in mounting and more mechanical security than traditional packages. International Rectifier’s rugged ceramic seal pins are used exclusively in the package thereby assuring long term hermeticity. HYBRID - HIGH RELIABILITY RADIATION TOLERANT DC/DC CONVERTER PD-94688C |
