DC Electrical Characteristics
For ACT Family Devices over Operating Temperature Range (unless otherwise specified).
Notes:
1. All outputs loaded; thresholds on input associated with input under test.
2. Test Load 50pF, 500
Ω to Ground.
AC Electrical Characteristics
Symbol
Parameter
VCC (V)
Conditions
TA = +25°C,
CL = 50pF
TA = –40°C to +85°C
Units
Typ.
Guaranteed Limits
VIH
Minimum HIGH
Level Input Voltage
4.5
VOUT = 0.1V
or VCC – 0.1V
1.5
2.0
2.0
V
5.5
1.5
2.0
2.0
VIL
Maximum LOW
Level Input Voltage
4.5
VOUT = 0.1V
or VCC – 0.1V
1.5
0.8
0.8
V
5.5
1.5
0.8
0.8
VOH
Minimum HIGH
Level Output Voltage
4.5
IOUT = –50 µA
4.49
4.4
4.4
V
5.5
5.49
5.4
5.4
4.5
VIN = VIL/VIH,
IOH = –8 mA
(1)
3.86
3.76
V
5.5
4.86
4.76
VOL
Maximum LOW
Level Output Voltage
4.5
IOUT = 50µA
0.001
0.1
0.1
V
5.5
0.001
0.1
0.1
4.5
VIN = VIL/VIH,
IOH = +8mA
(1)
0.36
0.44
V
5.5
0.36
0.44
IOLD
Minimum Dynamic
Output Current
5.5
VOLD = 1.65V
32.0
mA
IOHD
Minimum Dynamic
Output Current
5.5
VOHD = 3.85V
–32.0
mA
IIN
Maximum Input
Leakage Current
5.5
VI = VCC, GND
±0.1
±1.0
µA
ICC
Supply Current
Quiescent
5.5
VIN = VCC, GND
8.0
80
µA
ICCT
Maximum ICC/Input
5.5
VIN = VCC – 2.1V
0.6
1.5
mA
Symbol
Parameter
VCC (V)
TA = +25°C,
CL = 50pF
TA = –40°C to +85°C,
CL = 50pF
Units
Min.
Typ.
Max.
Min.
Max.
fMAXI
Interlaced fMAX
(HMAX/2 is ODD)
5.0
170
190
150
MHz
fMAX
Non-Interlaced fMAX
(HMAX/2 is EVEN)
5.0
190
220
175
MHz
tPLH1, tPHL1 Clock to Any Output
5.0
4.0
13.0
15.5
3.5
18.5
ns
tPLH2, tPHL2 Clock to ODDEVEN
(Scan Mode)
5.0
4.5
15.0
17.0
3.5
20.5
ns
tPLH3
Load to Outputs
5.0
4.0
11.5
16.0
3.0
19.5
ns
