6 / 20 page

AD8429

Rev. 0 | Page 6 of 20

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage

±18 V

Output Short-Circuit Current Duration

Indefinite

Maximum Voltage at –IN, +IN1

±VS

Differential Input Voltage1

Gain ≤ 4

±VS

4 > Gain > 50

±50 V/gain

Gain ≥ 50

±1 V

Maximum Voltage at REF

±VS

Storage Temperature Range

−65°C to +150°C

Specified Temperature Range

−40°C to +125°C

Maximum Junction Temperature

140°C

ESD

Human Body Model

3.0 kV

Charge Device Model

1.5 kV

Machine Model

0.2 kV

1 For voltages beyond these limits, use input protection resistors. See the

Theory of Operation section for more information.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θJA is specified for a device in free air using a 4-layer JEDEC

printed circuit board (PCB).

Table 3.

Package

θJA

Unit

8-Lead SOIC

121

°C/W

ESD CAUTION
