background image
STTS2002
Temperature sensor registers
Doc ID 15389 Rev 5
27/52
Note:
In all temperature register formats bits 0 and bits 1 are used when the resolution is more
than 10 bits. These registers show temperature data for the default 10 bits.
Table 18.
Critical temperature register format
Sign
MSB
LSB(1)
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit(2)
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit(3)
1
Bit(4)
0
000
Critical temperature trip point
00
1.
Bit 2 is LSB for default 10-bit mode.
2.
If critical trip lockout bit (bit 7 of configuration register in Table 9) is set, then this register becomes read-only.
3.
Depending on status of the resolution register, bit 1 may display 0.125 °C value.
4.
Depending on status of the resolution register, bit 0 may display 0.0625 °C value.
