 5 / 28 page
background image
ADL5812
Rev. 0 | Page 5 of 28
ABSOLUTE MAXIMUM RATINGS
Table 3.
Parameter
Rating
Supply Voltage, VPOS
5.5 V
CLK, DATA, LE
5.5 V
IF Output Bias
6.0 V
RF Input Power
20 dBm
LO Input Power
13 dBm
Internal Power Dissipation
2.5 W
θJA (Exposed Paddle Soldered Down)
30°C
Maximum Junction Temperature
150°C
Operating Temperature Range
−40°C to +85°C
Storage Temperature Range
−65°C to +150°C
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
