Data Sheet
ADL5336
Rev. B | Page 19 of 32
REGISTER MAP AND CODES
Table 5. Register Map
MSB
LSB
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
B0
VGA2 Maximum Gain
VGA1 Maximum Gain
VGA2 Switch
VGA2 Setpoint
VGA1 Setpoint
Table 6. RMS Output Setpoint Map
Setpoint Word
RMS Output (mV rms/dBV)
0
0
0
+62.5/−24
0
0
1
+88/−21
0
1
0
+125/−18
0
1
1
+176/−15
1
0
0
+250/−12
1
0
1
+353/−9
1
1
0
+500/−6
1
1
1
+707/−3
Table 7. VGA2 Input Switch Logic
VGA2 Switch
Selected Input
0
IP2A, IM2A
1
IP2B, IM2B
Table 8. Maximum Gain Map
Maximum Gain Word
VGA1 Maximum Gain (dB)
VGA2 Maximum Gain (dB)
0
0
9.5
14
0
1
12.0
16.9
1
0
14.0
19
1
1
15.6
20.9
