4 / 15 page ![]() CY25200 Document Number: 38-07633 Rev. *H Page 4 of 15 Programming Description Field-Programmable CY25200 The CY25200 is programmed at the package level, and must be programmed prior to installation on a circuit board. Field programmable devices are denoted by an “F” in the ordering code, and are blank when shipped. The CY25200 is Flash technology based, which allows it to be reprogrammed up to 100 times. This allows for fast and easy design changes and product updates, and eliminates issues with old and out of date inventory. Samples and small prototype quantities are programmed on the CY3672 programmer with the CY3695 socket adapter. CyberClocks Online Software CyberClocks Online Software is a web based software application that allows the user to custom configure the CY25200. All the parameters in Table 2 and Table 3 are entered as variables into the software. CyberClocks Online outputs an industry standard JEDEC file used for programming the CY25200. CyberClocks Online is available at www.cyberclocksonline.com website. Factory-Programmed CY25200 Factory programming by Cypress is available for high volume orders. All requests must be submitted to the local Cypress Field Application Engineer (FAE) or sales representative. After the request is processed, you will receive a new part number, samples, and data sheet with the programmed values. This part number is used for additional sample requests and production orders. Table 2. Fixed Function Pins Pin Function Output Clock Frequency Input Frequency CXIN and CXOUT Spread Percent Modulation Frequency Pin Name SSCLK[1:6] XIN and XOUT XIN and XOUT SSCLK[1:6] SSCLK[1:6] Pin# 7, 8, 9, 12, 14, 15 1 and 16 1 and 16 7, 8, 9, 12, 14, 15 7, 8, 9, 12, 14, 15 Units MHz MHz pF % and Center- or Down-spread kHz Program Value CLKSEL = 0 USER SPECIFIED USER SPECIFIED USER SPECIFIED USER SPECIFIED USER SPECIFIED Program Value CLKSEL = 1 USER SPECIFIED Table 3. Multi-Function Pins Pin Function Output Clock/REFOUT/OE/SSON/CLKSEL OE/PD#/SSON/CLKSEL Pin Name SSCLK5/REFOUT/CP2 SSCLK6/REFOUT/CP3 CP0 CP1 Pin# 14 15 4 10 Units Function Function Function Function USER SPECIFIED USER SPECIFIED USER SPECIFIED USER SPECIFIED [+] Feedback |
|
|
