PNP BD242 – A – B – C

23/10/2012

COMSET SEMICONDUCTORS

1/3

M

ME

ED

DIIU

UM

M P

PO

OW

WE

ER

R L

LIIN

NE

EA

AR

R A

AN

ND

D S

SW

WIIT

TC

CH

HIIN

NG

G

A

AP

PP

PL

LIIC

CA

AT

TIIO

ON

NS

S..

The BD242, A, B, C are the PNP transistors mounted in Jedec TO-220 plastic package.

They are the silicon epitaxial-base Power Transistors for use in medium power linear and

switching applications.

The NPN complements are BD241, A, B, C.

Compliance to RoHS.

ABSOLUTE MAXIMUM RATINGS

Symbol

Ratings

Value

Unit

VCEO

Collector-Emitter Voltage (IB = 0)

BD242

-45

V

BD242A

-60

BD242B

-80

BD242C

-100

VCER

Collector-Emitter Voltage (RBE = 100 Ω)

BD242

-55

V

BD242A

-70

BD242B

-90

BD242C

-115

VEBO

Emitter-Base Voltage (IC = 0)

BD242

-5.0

V

BD242A

BD242B

BD242C

IC

Collector Current

IC

-3

A

ICM

-5

IB

Base Current

-1

A

PT

Power Dissipation

@ Tamb = 25° C

2

W

@ Tcase = 25° C

40

W

TJ

Junction Temperature

150

°C

TS

Storage Temperature

-65 to +150

THERMAL CHARACTERISTICS

Symbol

Ratings

Value

Unit

RthJ-amb

Thermal Resistance, Junction-ambient

62.5

°C/W

RthJ-case

Thermal Resistance, Junction-case

3.13

°C/W
