REV. A
ADR380/ADR381
–7–
VIN = 2.5V TO 15V
TEMPERATURE ( C)
–40
–15
10
35
60
85
0
1
2
4
5
3
TPC 9. ADR380 Line Regulation vs. Temperature
VIN = 2.8V TO 15V
TEMPERATURE ( C)
–40
–15
10
35
60
85
0
1
2
4
5
3
TPC 10. ADR381 Line Regulation vs. Temperature
–40 C
LOAD CURRENT (mA)
01
2
3
4
5
0
0.2
0.4
0.6
0.8
+85 C
+25 C
TPC 11. ADR380 Minimum Input/Output
Voltage Differential vs. Load Current
–40 C
LOAD CURRENT (mA)
01
2
345
0
0.2
0.4
0.6
0.8
+85 C
+25 C
TPC 12. ADR381 Minimum Input/Output Voltage
Differential vs. Load Current
VOUT DEVIATION (ppm)
–260
0
10
20
30
40
50
60
–200 –140 –80 –20
40
100 160 220
340 400
280
TEMPERATURE +25 C
–40 C
85 C
+25 C
TPC 13. ADR381 VOUT Hysteresis
TIME (1s/DIV)
2 V/DIV
TPC 14. ADR381 Typical Noise Voltage 0.1 Hz to 10 Hz
