RoHS

LPS

LPS

LPS

LPS

Specifications

All Specifications are typical at nominal input, full load at 25°C unless otherwise stated.

AC Input

100-240VAC, -/-10%, 47-63 Hz, 1∅

MTBF

>100,000 hours (calculated)

Input Current

100VAC: 1.1A

Hold-up Time

18 ms min. @ 115Vac, 60 ms @ 230 Vac

Inrush Current

60 A peak, 264 V, cold start

Overload Protection

Hiccup Mode

Input Fuse

3.15A, 250V Internal Primary Current Fuse is provided

Short Circuit Protection

Hiccup Mode

Efficiency

Meets EISA2007, CEC Efficiency Level V,

EU (EC) No 278/2009 Phase II

Topology

Switching – Fixed Frequency Flyback

Output Voltage

See chart

Safety Standards

EN/IEC/CSA/UL60950-1, 2

Output Power

See chart

EMC

See chart below

Ripple and Noise

1% pk-pk max., 20MHz BW

Dielectric Withstand

Input-Output: 4,242Vdc

Input-GND: 1,500 Vac, Output-GND: 500Vdc

Line & Load Voltage Regulation

Line: +/- 1%, Load: +/-5%

Operating Temperature

0° to 40°C, no derating

Transient Response

500µs max., 50% load step, typical

Storage Temperature

-30 to +85°C

Minimum Load

Not required

Relative Humidity

5% to 95%, non-condensing

Case Material

Black 94V0 Polycarbonate

Altitude

0 to 10,000 ft

Case Dimensions

102 x 60 x 32mm. See outline drawing

Output Cable

#18AWG (UL1185), 1,500mm, 2 conductor

Weight

250g

Output Connector

2.5mm barrel type (Ault #3), center positive (+)

EMC Specifications

Conducted Emissions

EN55022 Class B, FCC Part 15, Class B.

Radiated Emissions

EN55022 Class B, FCC Part 15, Class B.

Line Frequency Harmonics

EN61000-3-2, Class A

Voltage Fluctuations/Flicker

EN61000-3-3

Static Discharge Immunity

EN61000-4-2, 6kV Contact Discharge, 8kV air discharge

Radiated RF Immunity

EN61000-4-3, 3V/m.

EFT/Burst Immunity

EN61000-4-4, 2kV/5kHz.

Line Surge Immunity

EN61000-4-5, 1kV differential, 2kV common-mode

Conducted RF Immunity

EN61000-4-6, 3Vrms

Power Frequency Magnetic Field Immunity

EN61000-4-8, 3A/m

Voltage Dip Immunity

EN61000-4-11, Criteria B

CENB1040

Universal 40 Watt Series

ITE Switch-Mode Power Supply

3 Year Warranty

•

100-240VAC Universal Input

•

Meets EISA2007, CEC Efficiency Level V,

EU (EC) No 278/2009 Phase II

•

Desktop Style

•

Limited Power Source

•

Certified to UL/EN60950-1, 2nd Edition

•

5V to 48V Single Output Models, up to 40W

•

Modified and Custom Designs Available

•

Regulated Output with Low Ripple

•

No Load Power Consumption <0.3W

•

Impact-Resistant Polycarbonate Enclosure
