AD5625R/AD5645R/AD5665R, AD5625/AD5665

Data Sheet

Rev. C | Page 10 of 36

ABSOLUTE MAXIMUM RATINGS

TA = 25°C, unless otherwise noted.

Table 6.

Parameter

Rating

VDD to GND

−0.3 V to +7 V

VOUT to GND

−0.3 V to VDD + 0.3 V

VREFIN/VREFOUT to GND

−0.3 V to VDD + 0.3 V

Digital Input Voltage to GND

−0.3 V to VDD + 0.3 V

Operating Temperature Range, Industrial

−40°C to +105°C

Storage Temperature Range

−65°C to +150°C

Junction Temperature (TJ maximum)

150°C

Power Dissipation

(TJ max − TA)/θJA

θJA Thermal Impedance

LFCSP_WD (4-Layer Board)

61°C/W

TSSOP

150.4°C/W

WLCSP

75°C/W

Reflow Soldering Peak Temperature,

RoHS Compliant

260°C ± 5°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION

AD5665RBCPZ-R2 Arkusz danych(PDF) 10 Page - Analog Devices
