AD8331/AD8332/AD8334

Rev. G | Page 53 of 56

OUTLINE DIMENSIONS

COMPLIANT TO JEDEC STANDARDS MO-153-AE

8°

0°

SEATING

PLANE

COPLANARITY

0.10

1.20 MAX

6.40 BSC

0.65

BSC

PIN 1

0.30

0.19

0.20

0.09

4.50

4.40

4.30

0.75

0.60

0.45

9.80

9.70

9.60

0.15

0.05

Figure 122. 28-Lead Thin Shrink Small Outline Package (TSSOP)

(RU-28)

Dimensions shown in millimeters

COMPLIANT TO JEDEC STANDARDS MO-137-AD

CONTROLLING DIMENSIONS ARE IN INCHES; MILLIMETERS DIMENSIONS

(IN PARENTHESES) ARE ROUNDED-OFF INCH EQUIVALENTS FOR

REFERENCE ONLY AND ARE NOT APPROPRIATE FOR USE IN DESIGN.

SEATING

PLANE

0.010 (0.25)

0.004 (0.10)

0.012 (0.30)

0.008 (0.20)

0.025 (0.64)

BSC

0.041 (1.04)

REF

0.010 (0.25)

0.006 (0.15)

0.050 (1.27)

0.016 (0.41)

0.020 (0.51)

0.010 (0.25)

8°

0°

COPLANARITY

0.004 (0.10)

0.065 (1.65)

0.049 (1.25)

0.069 (1.75)

0.053 (1.35)

0.345 (8.76)

0.341 (8.66)

0.337 (8.55)

0.158 (4.01)

0.154 (3.91)

0.150 (3.81) 0.244 (6.20)

0.236 (5.99)

0.228 (5.79)

Figure 123. 20-Lead Shrink Small Outline Package (QSOP)

(RQ-20)

Dimensions shown in Inches and (millimeters
