AD8436

Data Sheet

Rev. B | Page 4 of 24

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Voltage

Supply

±18 V

Input

±VS

Differential Input

+VS and −VS

Power Dissipation

CP-20-10 LFCSP Without Thermal Pad

1.2 W

CP-20-10 LFCSP With Thermal Pad

2.1 W

RQ Package

1.1 W

Output Short-Circuit Duration

Indefinite

Temperature

Operating Range

−40°C to +125°C

Storage Range

−65°C to +125°C

Lead Soldering (60 sec)

300°C

θJA

CP-20-10 LFCSP Without Thermal Pad

86°C/W

CP-20-10 LFCSP With Thermal Pad

48°C/W

RQ-20 Package

95°C/W

ESD Rating

2 kV

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

ESD CAUTION
