Data Sheet
ADA4075-2
Rev. B | Page 13 of 24
1
10
1
10
100
1k
10k
100k
FREQUENCY (Hz)
VSY = ±15V
Figure 45. Voltage Noise Density
1
10
100
1k
10k
100k
FREQUENCY (Hz)
0.1
1
10
CORRELATED
RS1 = RS2
UNCORRELATED
RS1 = 0Ω
VSY = ±15V
RS1
RS2
Figure 46. Current Noise Density
TIME (1s/DIV)
VSY = ±15V
Figure 47. 0.1 Hz to 10 Hz Noise
1
10
1
10
100
1k
10k
100k
FREQUENCY (Hz)
VSY = ±5V
Figure 48. Voltage Noise Density
1
10
100
1k
10k
100k
FREQUENCY (Hz)
0.1
1
10
CORRELATED
RS1 = RS2
UNCORRELATED
RS1 = 0Ω
VSY = ±5V
RS1
RS2
Figure 49. Current Noise Density
TIME (1s/DIV)
VSY = ±5V
Figure 50. 0.1 Hz to 10 Hz Noise
