ADL5350

Rev. 0 | Page 8 of 24

Supply voltage = 3 V, RF frequency = 850 MHz, IF frequency = 70 MHz, RF level = 0 dBm, LO level = 4 dBm, TA = 25°C, unless otherwise noted.

+25°C

–40°C

+85°C

2.7

3.5

3.4

3.3

3.2

3.1

3.0

2.9

2.8

SUPPLY VOLTAGE (V)

Figure 9. Input IP3 vs. Supply Voltage

+25°C

–40°C

+85°C

2.7

3.5

3.4

3.3

3.2

3.1

3.0

2.9

2.8

SUPPLY VOLTAGE (V)

Figure 10. Input P1dB vs. Supply Voltage

8.0

5.0

5.5

6.0

6.5

7.0

7.5

2.7

3.5

3.4

3.3

3.2

3.1

3.0

2.9

2.8

SUPPLY VOLTAGE (V)

Figure 11. Noise Figure vs. Supply Voltage

750

975

950

925

900

875

850

825

800

775

RF FREQUENCY (MHz)

–40°C

+25°C

+85°C

Figure 12. Supply Current vs. RF Frequency

7.6

7.4

7.2

7.0

6.8

6.6

6.4

6.2

6.0

5.8

750

800

850

900

950

RF FREQUENCY (MHz)

–40°C

+25°C

+85°C

Figure 13. Conversion Loss vs. RF Frequency

27.0

22.0

22.5

23.0

23.5

24.0

24.5

25.0

25.5

26.0

26.5

750

975

950

925

900

875

850

825

800

775

RF FREQUENCY (MHz)

–40°C

+25°C

+85°C

Figure 14. Input IP3 vs. RF Frequency
