1 / 3 page

NPN BU911

21/11/2012

COMSET SEMICONDUCTORS

1 | 3

HIGH VOLTAGE POWER DARLINGTON

The BU911 are high voltage, silicon NPN transistors in monolithic Darlington mounted in Jedec

TO-220 plastic package.

They are designed for applications such as electronic ignition, DC and AD motor controls,

solenoid drivers, etc.

Compliance to RoHS.

ABSOLUTE MAXIMUM RATINGS

Symbol

Ratings

Value

Unit

VCEO

Collector-Emitter Voltage

400

V

VCES

Collector-Emitter Voltage

Vbe=0

450

V

VEBO

Emitter-Base Voltage

5

V

IC

Collector Current

6

A

ICM

Collector Current Peak

10

A

IB

Base Current

1

A

PD

Total Device Dissipation

@ TC = 25°

60

W

TJ

Junction Temperature

150

°C

TStg

Storage Temperature Range

-65 to +150

°C

THERMAL CHARACTERISTICS

Symbol

Ratings

Value

Unit

RthJ-c

Thermal Resistance, Junction to case

2.08

°C/W
