AD8305

Rev. B | Page 13 of 24

the input compensation network and C2 is the recommended

bypassing capacitor on VSUM.

If board space limits the amount of external circuitry to the

AD8305 it is possible to eliminate the transistor in Figure 34

and connect the resistor divider directly to VSUM. In this case

the bias voltage at VSUM and INPT is set by the resistor values

selected for the divider, not the internal biasing of the AD8305.
