t

User direction of feed

Cross section A - B

p

p

H

Reference plane

W

A

B

F

L

h

h

IEC

EIA

Dimensions

Dimension Description

Mark

Mark

Dimensions

Tolerance

Lead spacing: MF-RHT070 ~ MF-RHT750

F

F

5.08

-0.2/+0.8

(0.2)

(-0.006/+0.031)

Lead spacing: MF-RHT1300

F

F

10.2

-0.2/+0.8

(0.402)

(-0.006/+0.031)

Reel width: MF-RHT070 ~ MF-RHT450

w

W2

56

max.

(2.20)

Reel width: MF-RHT650 ~ MF-RHT1300

w

W2

63.5

max.

(2.50)

Reel diameter

d

a

370.0

max.

(14.57)

Space between flanges less device

4.75

±3.25

W1

h

(.187)

(±.128)

Arbor hole diameter

f

c

26.0

±12.0

(1.02)

(±.472)

Core diameter

h

n

80.0

max.

(3.15)

Box

62

355

345

(2.44) (14.0)

(13.6)

Consecutive missing places

3

max.

Empty places per reel

Not specified

MF-RHT Series Tape and Reel Specifications

Specifications are subject to change without notice.

The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.

Users should verify actual device performance in their specific applications.

Taped Component Dimensions - Figure 1

Reel Dimensions - Figure 2

DIMENSIONS:

MM

(INCHES)

h

w

h

f

d

Reel

Upper side

Tape

Lower side

User

direction

of

feed
