GS1AF THRU GS1MF

SURFACE MOUNT GENERAL RECTIFIER

Reverse Voltage - 50 to 1000 Volts

Forward Current - 1.0 Ampere

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

GS1AF

VOLTS

VOLTS

VOLTS

SYMBOLS

UNITS

Amp

Amps

Volts

1.0

30.0

1.1

Operating junction and storage temperature range

Maximum repetitive peak reverse voltage

Maximum RMS voltage

Maximum DC blocking voltage

Maximum average forward rectified current

Peak forward surge current

8.3ms single half sine-wave superimposed on

rated load (JEDEC Method)

Maximum instantaneous forward voltage at 1.0A

Maximum DC reverse current

at rated DC blocking voltage

Typical junction capacitance (NOTE 1)

Note:1.Measured at 1MHz and applied reverse voltage of 4.0V D.C.

2.P.C.B. mounted with 0.2x0.2

”(5.0x5.0mm) copper pad areas

5.0

50.0

R

75.0

15.0

-50 to +150

pF

C

A

µ

Typical thermal resistance (NOTE 2)

C/W

Ratings at 25 C ambient temperature unless otherwise specified.

Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%.

GS1BF

GS1DF GS1GF

GS1JF

GS1KF

GS1MF

50

35

50

100

70

100

200

140

200

400

280

400

600

420

600

800

560

800

1000

700

1000

Dimensions in inches and (millimeters)

FEATURES

MECHANICAL DATA

MDD Catalog Number

SMAF

Cathode Band

Top View

0.128(3.25)

0.144(3.65)

0.189(4.80)

0.173(4.40)

0.110(2.80)

0.094(2.40)

0.051(1.30)

0.059(1.50)

0.055(1.40)

0.043(1.10)

0.012(0.30)

0.006(0.15)

0.047(1.20)

0.028(0.70)

The plastic package carries Underwriters Laboratory

Flammability Classification 94V-0

For surface mounted applications

Low reverse leakage

Built-in strain relief,ideal for automated placement

High forward surge current capability

High temperature soldering guaranteed:

260 C/10 seconds at terminals

Glass passivated chip junction

Case: JEDEC SMAF molded plastic body over passivated chip

Terminals: Solder plated, solderable per MIL-STD-750,

Method 2026

Polarity: Color band denotes cathode end

Mounting Position: Any

Weight:0.0018 ounce, 0.064 grams

２０１４－０３　０１版

ｈｔｔｐ：／／ｗｗｗ．ｍｉｃｒｏｄｉｏｄｅ．ｃｏｍ
