34 / 45 page

Package mechanical data

M24C64-W M24C64-R M24C64-F

34/45

DocID16891 Rev 30

Figure 18. TSSOP8 – 8-lead thin shrink small outline, package outline

1. Drawing is not to scale.

Table 19. TSSOP8 – 8-lead thin shrink small outline, package mechanical data

Symbol

millimeters

inches(1)

1. Values in inches are converted from mm and rounded to four decimal digits.

Typ.

Min.

Max.

Typ.

Min.

Max.

–

1.200

–

0.0472

–

0.050

0.150

–

0.0020

0.0059

1.000

0.800

1.050

0.0394

0.0315

0.0413

–

0.190

0.300

–

0.0075

0.0118

–

0.090

0.200

–

0.0035

0.0079

–

0.100

–

0.0039

3.000

2.900

3.100

0.1181

0.1142

0.1220

0.650

–

0.0256

–

6.400

6.200

6.600

0.2520

0.2441

0.2598

4.400

4.300

4.500

0.1732

0.1693

0.1772

0.600

0.450

0.750

0.0236

0.0177

0.0295

1.000

–

0.0394

–

0°

8°

–

0°

8°
