* All specifications and photos are subject to change without notice.

IFO2175-873

Features

17" TFT Fanless Super Slim Touch

Panel Computer with Intel® Core™

i7/i5/i3 & Celeron® Processor

(Ivy Bridge) & Celeron® processor

IPX1)

Introduction

Specifications

The IFO2175-873 is a slim panel computer equipped with a 17-inch 350 nits high

brightness SXGA LCD display that supports an 3rd Generation Intel® Core™ i7/ i5/ i3 and

Celeron® processors up to 35W with Intel® QM77 chipset. The Intel® HD Graphics

engine with DX11 support is built into the chipset to provide fast graphics performance.

The panel also supports DualView and multiple I/O options including 4 USB and

1 RS-232/422/485 ports. The built-in 5 mega pixels camera and microphone/speakers

can provide a solution for VoIP and remote monitoring. The IFO2175-873 also supports an

antenna for wireless (802.11 b/g/n) connection. Its dual Gigabit Ethernet ports provide

high speed Ethernet as well as a high reliable redundancy host connection. This robust

unit is designed to be work under minimal noise levels, low power consumption, high

reliability and while maintaining efficient performance. Its excellent industrial design (ID)

and user friendly interface design make it an ideal solution best suited for infotainment,

advertising messaging, and other digital signage applications.

Water/dust-proof design for entire system: IPX1

The IPX1-rated water/dust-proof housing protects the entire system from outside damage

caused by water drip damage while installed at public or enclosed environments. Its

unique design improves system stability while saving time and money on maintenance

costs and re-installation time.

Front Bezel

Plastic ABS

LCD Panel

Display Type

17” SXGA TFT LCD

Brightness (cd/m

350 nits

Resolution

1280 x 1024

Viewing Angle (H/V) 178°/178°

Main System

CPU

Socket rPGA988B 3rd Generation

Intel® Core™ i7/i5/i3 & Celeron®

processor, TDP up to 35W

Chipset

Intel

System Memory

2 x 204-pin DDR3 SO-DIMM max.

up to 16 GB

BIOS

AMI UEFI BIOS with OA 3.0 built

Storage

1 x 2.5" SATA HDD

1 x mSATA

Optical Drive

1 x Super Multi drive (optional)

Watchdog Timer

255 levels, 0~255 sec.

Onboard Graphics

Intel® HD Graphic

Fanless

Low Power

DualView

IP65

IPX1

DDR3

DDR3

DDR3

7. COM 1

(RS-232/422/485)

8. Gigabit LAN x 2

9. USB 2.0 x 2

10. USB 3.0 x 2

11. Audio (Line-out/Mic-in)

12. DisplayPort

1. Brightness Adjust buttons

2. Volume adjust buttons

3. Power LED

4. MIC

5. Power on/off button

6. Speaker (R)

13. Power connector

14. Power switch

15. PCI or PCIe slot

16. Speaker (L)

1

3

5

2

4

Camera

8 9

12

14

15

13

10

7

11

6

16
