www.roithner-laser.com
3
Outline Dimensions
All Dimensions in mm
Operating Regime
We recommend to use Quasi Continuous Wave (qCW) mode with duty cycle 50% or 25% to obtain maximum
average optical power, and short Pulse mode to obtain maximum peak power.
CW (continuous wave) mode is NOT recommended!
LED23
TO-18, without window
Material – kovar, finish – gold/plating
Lead
Description
PIN 1
LD Anode
PIN 2
LD Cathode
LED Basic Circuit Connection
Suitable Drivers And Evaluation Boards
•
D-31M
•
D-41
•
D-51
•
mD-1c
•
mD-1p
Quasi Continuous Wave (qCW) mode
Pulse Mode
