3 / 6 page

PUSB220

TVS

UNISONICTECHNOLOGIESCO.,LTD

3 of 6

www.unisonic.com.tw

QW-R215-007.B



ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

DC Input Voltage Range

VIN

0~+5.5

ESD Voltage (HBM Contact)

VESD

-8~+8

Storage Temperature

TSTG

-55~+125

°C

Operating Temperature Range

TOPR

-40~+85

°C

Note: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. IEC 61000-4-2 level 4.



ELECTRICAL CHARACTERISTICS (T

C=25

°C unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX UNIT

Pin Capacitance to Ground, Pins 1, 3, 4, 6

CI/O

VIN=0V, f =1MHz, VCC=3.0V

1.0

Diode Reverse Leakage Current, Pins 1, 3,

4, 6 to Ground

IlKG

VI=3.0V

100

Zener Diode Capacitance to

Ground, Pin 5 to 2

CZENER

VIN=0V, f =1MHz, VCC=3.0 V

Zener Diode Breakdown Voltage,

Pin 5 to 2

VBR I/O

I=1mA

Forward Voltage

0.7
